Easy Operation Customized Steel Metal Sheet Decking Floor Roll Forming Machine With PLC Control System

Introduction of Decking Floor Roll Forming Machine

Main Technical Specifications of Decking Floor Roll Forming Machine

• Raw Material: Galvanized steel sheets with strength 325Mpa
• Material Thickness: 0.8-1.2mm
• Material Width: 1220mm (depend on profile)
• Decoiler: Manual or Hydraulic type
• Roller Stand: about 24 stations (Depend on final design)
• Shaft Diameter: 80mm
• Roller material: Gcr15 steel, quenched and heated process, HRC58-62
• Shaft material: First grade 45# steel, heated and quenched
• Main motor power: 22KW
• Hydraulic station power: 3.0KW
• Forming speed: 10-12m/min
• Cutting type: Hydraulic cutting
• Blade material: Cr12 quenched treated
• Hydraulic Pressure: 10-12Mpa
• Controlling system: PLC

Main Components

Working Flowing of Decking Floor Roll Forming Machine

Decoiler ---- Feeding guide Device ---- Roll Forming ---- Cutting Device ---- Support Table

Reference Profile Drawing

Applications

Steel floor deck, metal deck, steel deck, metal decking sheet, steel structure floor deck...

Competitive Advantages

• High Quality
• Reliable
• Durable
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience

More Machine Pictures

Contact Details

Wuxi Techwell Machinery Co.,Ltd is a professional manufacturer specializing in the developing and exporting of cold roll forming machines and insulated sandwich panel machines and Slitting cutting machines.

Roll Forming Machines: Metal roof & wall panel roll forming machine, steel tile roll forming machine, dual level roll forming machine, C/Z/U/L shaped steel roll forming machine, drywall stud and track roll forming machine, steel floor deck roll forming machine, highway guardrail roll froming machinem downspout roll forming machine, rainwater gutter roll forming machine, portable downspout / gutter machines, door frame roll forming machine, roller shutter door roll forming machine, no-girder k span arched panel roll forming machine, slitting & cutting, roof curving machine, stacker machine and so on.

Insulated Sandwich Panel Machines: PU sandwich panel machine, rubber belt pu sandwich panel machine, continuous pu sandwich panel machine, EPS sandwich panel machine, rockwool sandwich panel machine, eps & rockwool sandwich panel machine, mineral wool sandwich panel machine and so on.

Wuxi Techwell engaged in the steel structure industry in many years and devoted to developing some steel structure machines with a professional technology and reasonable price, we supply the best machines for our new and old customers. In paticular, we are a leading exporter in the field of steel structure construction, and can provide professional service, high quality, through design and installation. Our goal is " Future by heartiness, faith leads to the world".

Warmly welcome to visit our factory and we are looking forward to cooperating with you for mutual benefits.
