    Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet

    Ask Lasest Price
    Brand Name : TECHWELL
    Model Number : TW-GTM
    Certification : CE
    Price : Contact Us
    Payment Terms : 40% T/T in advance, 60% T/T before shipment
    Supply Ability : 20 sets
    Delivery Time : 55-65 working days
    • Product Details
    • Company Profile

    Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet

    Steel Glazed Roof Step Tile Roll Forming Machine With Hydraulic Type Pressing For Making Steel Roofing Sheet

    Features of Tile Roll Forming Machine

    1. This roll forming machine can rollform metal roofing step tile. After roll formed by this roll forming machine, the surface will be very smooth and beautiful without any scratch on surface.

    2. Consists of uncoiled and its base, coil sheet guidingequipment, film covering device, roll forming system, forming step effect, post-cutting equipment, hydraulic station, controlling system and supportertable

    3. Fully Automatic Control System with PLC.

    4. Easy operation: Key in the length and quantity on the control panel.

    5. We also can do a custom roll forming machine, We can design the machine according to your specification and profile drawing.

    6. One roll forming machine only can produce one profile.



    Main Components of Tile Roll Forming Machine

    • Decoiler / Uncoiler----------------------------------------------------------------------1 Unit
    • Feeding Guide---------------------------------------------------------------------------1 Unit
    • Main Roof Step Tile Roll Forming Machine-----------------------------------------1 Unit
    • Hydraulic Pressing for Step------------------------------------------------------------1 Unit
    • Hydraulic Cutting System---------------------------------------------------------------1 Unit
    • Hydraulic Station-------------------------------------------------------------------------1 Unit
    • PLC Computer Control Box------------------------------------------------------------1 Unit
    • Support Tables---------------------------------------------------------------------------2 Units


    Technical Parameters of Glazed Step Tile Roll Forming Machine

    No.ItemParameterRemark
    1Suitable MaterialTypePPGI
    Yield strength300Mpa
    WidthDepend on drawing
    Thickness0.3-0.8mm
    2Forming Station≈ 17Depend on final design
    3Forming Speed≈ 0-15m/min excluding cutting
    4Roller MaterialHigh grade 45# steelWith Hard Chrome
    5Drive TypeChain Drive
    6Shaft DiameterΦ76mm
    7BearingHab Bearing
    8Pressing Die40CR
    9Cutting ModelHydraulic CuttingStop to cutting
    10Power SourceType380V/3PH/50HZDepend on requirement
    Main Power≈ 7.5KW
    Hydraulic Power≈ 5.5 KW
    11Electric Control SystemPLC-PANASONIC

    Operation:
    Screen + Button

    Inverter -YASKAWA
    Touch Screen -MCGS
    Encoder -OMRON
    12Machine Dimension≈ 9000mmX1500mmX1500mm(LXWXH)
    13Machine Weight≈ 7.8T



    Glazed Roof Step Tile Forming Machine Reference Profile Drawing








    Working Flowing


    Decoiler --- Fedding Guide --- Film Covering --- Roll Forming --- Pressing --- Cut-to-length --- Run out

    table


    Applications of Step Tile Roll Former


    Glazed tile, Roof Tile, Metal roof tile; steel roof tile; color steel tile; color glazed tile; wave tile; steel roofing

    sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding


    Output Table Reference Tile Products





    More Machine Pictures of Tile Roll Forming Machine






    Contact Deatails

    CompanyWuxi Techwell Machienry Co.,Ltd
    Website

    www.wxtechwell.com
    www.cold-rollformingmachine.com

    E-mail / Skypesales@wxtechwell.com
    Mob / Whatsapp+86-15861597732
    Reference video link

    https://youtu.be/N8FyrCI_Vsw
    https://youtu.be/z6DkyOttmxg
