PPGI, Color Steel, GI Corrugated Sheet Roll Forming Machine With 0-15m/Min Forming Speed, 0.3-0.8mm Thickness of Coil Sheet

Description of Corrugated Sheet Roll Forming Machine

• The flat steel corrugated roll forming machine is used to press 0.3-1mm thick colored steel sheets through a rolling and cold bending process to form wave pattern sheets. These colored wave pattern sheets will then be used in the construction industry for roofs, interior walls, and external wall boards for storehouses, residential homes, or industrial places and worksites.

• The wave sheets resulting from the use of the flat steel corrugated roll forming machine are light weight, strong, and come in multiple colors. They are earthquake proof and fireproof, as well as featuring other useful characteristics for construction projects. In order to meet all requirements for high and low strength sheets, Wuxi Techwell has improved the design of the forming press. A herringbone roller was added between the wave crests of the frames to give the pressed sheet its flat and beautiful appearance, as well as its strength.

• Each roller on the flat steel corrugated roll forming machine are forged through intense processes using high quality steel. Processes include high frequency hardening, quenching and hardening, and their surfaces are then plated with hard chromium to make them smooth and wear resistant. The flat steel corrugated roll forming machine has a computer to control the length and other measurements.

Main Specifications of Corrugated Sheet Roll Former

Main Components of Corrugated Sheet Roll Former

• Decoiler / Uncoiler-----------------------------------------------------------------------------1 Unit
• Feeding Guide---------------------------------------------------------------------------------1 Unit
• Main Corrugated Sheet Making Machine-------------------------------------------------1 Unit
• Hydraulic Cutting Device---------------------------------------------------------------------1 Unit
• Hydraulic Station-------------------------------------------------------------------------------1 Unit
• PLC Computer Control Board---------------------------------------------------------------1 Unit
• Support Tables---------------------------------------------------------------------------------1 Unit

Working Flow

Decoiler --- Fedding Guide --- Roll Forming --- Cut-to-length --- Run out table

Corrugated Sheet Roll Former Reference Drawing

Applications of Corrugated Sheet

Metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet;

metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding

Output Table Products

Our Advantaegs

• Copra designing software
• 5-8 technicians every month specially do international installation and debugging
• High Quality
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience

More Machine Pictures
