U Shaped Seamless Gutter Roll Forming Machine for Making Steel Rainwater Gutter

This gutter roll forming machine line consists of Decoiler, Feeding guide, main roll forming machine, Hydraulic cutting device , Hydraulic Station, PLC computer control, Output table. They are widely used as the roof of garden like factory, hotel, exhibition center, villa, civil construction, etc.

A). Main Specification of Seamless Gutter Forming Machine

• Material thickness: 0.4-0.8mm
• Decoiler: Manaul or hydraulic decoiler
• Weight capacity of decoiler: 3 Ton
• Forming Station: 16
• Main motor power: 3KW
• Hydraulic power: 7.5KW
• Forming Speed: 0-15m/min
• Cutting blade material: Cr12 mould steel with quenched treatment.
• Cutting: Hydraulic cutting
• Drive: Chain transmission
• Electrical Control: PLC Frequency Control System with touch screen
• PLC: PANASONIC Brand
• Encoder: OMRON Brand
• Transducer: PANASONIC Brand
• They are widely used as the roof of garden like factory, hotel, exhibition center, villa, civil construction, etc.
• Roller material: high grade NO.45 forged steel, plated hard chrome on the surface of roller with thickness 0.05mm.

B). Main Components of Seamless Gutter Forming Machine

1. Decoiler ---------------------------------------------- 1 Unit
2. Feeding guide -------------------------------------- 1 Unit
3. main roll forming machine ------------------------ 1 Unit
4. Hydraulic cutting device -------------------------- 1 Unit
5. Hydraulic Station ----------------------------------- 1 Unit
6. PLC computer control ----------------------------- 1 Unit
7. Output table ----------------------------------------- 1 Unit

C). Working Flow of Seamless Gutter Forming Machine
Decoiler--> Coil sheet guiding and feeding --> Roll forming machine --> Cut to length --> Out-put Table

D). Application

Rainwater gutter, k gutter, half round gutter, box gutter

They are widely used as the roof of garden like factory, hotel, exhibition center, villa, civil construction, etc.


E). Competitive Advantages

1.Durable and widely used products
2.Simple to operate when assemble
3.Easy to handle the products
4.Direct manufacturer, provide with high quality and best price.
5.Provide sample in free.
6.Cutting service.
7.Products and design solution supplied fast and freely
8.Best design oriented for your special requirements
9.Lifelong technical support
10.Professional team support
11.Standard Design


F). Machine Pictures



G). Factory Pictures



H). More Contact Methods & Reference Videos

I). FAQ

1)Q: Do you have instruction manuals?
A: We provide you with instruction manuals, electricity layouts, civil requirements, and machine drawings.

2)Q: Once a machine arrives at our factory what happens then?
A: We will send you a technician or engineer that will commission and install your machine, with training for your staff if required at a separate fee.

3)Q: What do I need to offload my machine from the container?
A: You are not responsible for the offloading of your machinery, and it is recommended that you use a reputable rigging company.

4)Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the world. We need your machines running in order to keep your business running.
5) Q: How do your machines compare with other big companies in this market?
A: We are up to date with the latest technology and improve our machines accordingly
6)Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality control from the very
beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.

7) Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.

8) Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. The core of our company culture is honesty and credit. We have good reputation in this field for ten years' experience.
