Special U Shaped Purlin Rolling Former Machine for Making U Purlin Profile with Pre-cutting & Pre-punching

A). Technical Specifications of U Purlin Forming Machine

• Material: HRC, CRC, GI
• Coil Material Thickness:1.5-3.0mm
• Coil width Custom-made
• Yield Strength: 235Mpa
• Material: Q235
• Decoiler/ Uncoiler Coil Width: Max. 350mm
• I.D: 300mm
• O.D: Max. 560mm
• Roll Forming Machine Forming stations: 14 Stations ( Depend on Profiles )
• Roller material: GCr15 steel, HRC58-62
• Diameter of shaft: 70mm
• Shaft material: GCr15 steel, quenched and heated process, HRC58-62
• Drive type: Chain Transmission
• Forming speed: 0-15m/min
• Main power: 11KW
• Cutting Cutting type: Hydraulic Pre-cutting
• Punching: Hydraulic Pre-cutting
• Cutting Tolerance: 10m+/-0.5mm
• Encoder: OMRON Brand
• Electrical control: PLC Delta Brand or Custom-made
• Inverter: Delta Brand or Custom-made
• Touch screen: Delta Brand or Custom-made
• Operation type: Touch screen & Button
• Runout Table: Table type Simple nonpower type
• Function: To support the finished panels

B). Main Components of U Purlin Forming Machine

Decoiler -------------------------------------------- 1 Unit

Feeding & Leveling -------------------------------- 1 Unit

Main roll forming machine ------------------------ 1 Unit

Hydraulic cutting device --------------------------- 1 Unit

Hydraulic Station ----------------------------------- 1 Unit

PLC computer control ------------------------------ 1 Unit

Output table ---------------------------------------- 1 Unit

C). Working Flow of U Purlin Forming Machine

E). Competitive Advantages

• Easy to operate

a. High efficiency
b. Low energy consumption

c. Reliable working

• After-sales service

a. Technical Support
Fully providing technology supports both within and after the warranty period. Feed back to our customers at the first time.

b. Spare Parts
Promptly providing spare parts and wearing parts.

c. Upgrade
Improve technology and upgrade of equipments.

ONE-Years warranty, whole life service.

• Professional: More than 10 years' rich experience!

a.Specialized in Manual Curved Arch Roof Sheet Forming Machine;

b.Keeping improving the quality.

• OEM/ ODM

a. Customers’ design, color & logo are accepted

b. Our outstanding experts and skilled workers are devoting their hard working, to ensure the machine with high quality.

• ONE-Years warranty, whole life service.

Within the ONE-YEARS period, we could offer the replacement parts to the client free of charge for any parts damaged due to quality problems .

G). More Machine Pictures

H). Customer Visiting

I). Machine To Container

J). FAQ

1. How to get a accurate quotation from us?
a. Material width and thickness. b. drawing of profile.
As for the drawing, you can provide by yourself, or choose from our standard profiles.

2. How to repair & maintain our U Shaped Purlin Roll Forming Machine?

a. Normally, the machine can work without problem for at least 5 years.
b. If you have problem, do not change the machine by yourself. Tell us the problem, and we help you to solve it step by step.

3. What policy for broken parts?
Within the ONE-YEAR period, we could supply you the replacement parts free of charge for any damaged parts caused by quality problems. After two years, you need to buy by factory cost.
