Floor Decking Sheet Cold Roll Former for Making 0.8 --1.0 mm Thickness Steel Structure Floor Decking Panel

A). Introduction

The floor deck produced by Floor deck roll forming machine is used for floor decking in building.

This series product is suitable for steel structure factory and public great building.

B). Main Specifications

1. Material Spec: Galvanized steel sheet
2. Thickness of Coil Sheet: 0.8 --1.0 mm
3. Main Motor Power: 18.5kw
4. Forming Speed: 10--12m/min
5. Hydraulic Station Power: 4kw
6. Quantity of Stands: About 24 groups
7. Controlling System: PLC
8. Index Error of Length: 10m±1.5mm
9. Hydraulic Pressure: 10~12Mpa
10. Total Weight: About 1800kg
11. Voltage: 380V 3 phase 50Hz or at buyers requirement

C). Main Components

D). Working Flow

Decoil -- Feeding -- Roll Forming -- Automatic Cutting -- Output Table

E). Competitive Advantages

1. Durable and widely used products

2. Simple to operate when assemble

3. Easy to handle the products

4. Direct manufacturer, provide with high quality and best price.

5. Provide sample in free.

6. Cutting service.

7. Products and design solution supplied fast and freely

8. Best design oriented for your special requirements

9. Lifelong technical support

10. Professional team support

11. Standard Design

12. Concept proposal

13. 3D Drawing

F). Machine Products Pictures

G). Output Products Pictures

H). Applications

Steel floor deck, metal deck, steel deck, metal decking sheet, steel structure floor deck...
