    Steel Double Layer Roof Roll Forming Machine / Roofing Sheet Roll Forming Machine

    Ask Lasest Price
    Brand Name : TECHWELL
    Model Number : TW-DLM100
    Certification : CE
    Price : Contact Us
    Payment Terms : T/T
    Supply Ability : 20 sets
    Delivery Time : 55-65 Working Days
    • Product Details
    • Company Profile

    Steel Double Layer Roof Roll Forming Machine / Roofing Sheet Roll Forming Machine

    Steel Double Layer Roofing Sheet Roll Forming Machine for Making Two Different Roof Wall Panel Profiles


    A). Main Specifications

    • Material thickness: 0.3-0.8mm
    • Material width: depend on customer’s requirement
    • Decoiler Type: manual or automatical type ( depend on customer’s requirement )
    • Weight Capacity Of Decoiler: 5 Ton
    • Main Motor Power: 7.5 Kw
    • Hydraulic Motor Power: 3 Kw
    • Forming Station: approx 18 & 18 ( depend on profile drawing )
    • Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
    • Main Axis Material: High grade 45#, quenched and heat treatment.
    • Axis Diameter: ¢ 75mm
    • Working Speed: 0-15 m/min
    • Transporting Type: Chain Transmission
    • Heat Treatment of Cutting Blade: HRC 50-60
    • Type of Cutting: Hydraulic cutting
    • Material Of Cutting Blade: C r 12
    • Heat Treatment of Cutting Blade: HRC 50-60
    • Machine Frame stand: Welded structural steel
    • Thickmess of Fame Steel: 18mm
    • Electrical Control: PLC Frequency Control System with touch screen
    • PLC: PANASONIC Brand
    • Encoder: OMRON Brand
    • Transducer: PANASONIC Brand
    • Machine Weight: about 8.5 Ton

    B). Main Components


    Decoiler -------------------------------------------- 1 Unit

    Feeding guide -------------------------------------- 1 Unit

    main roll forming machine ------------------------ 1 Unit

    Hydraulic cutting device --------------------------- 1 Unit

    Hydraulic Station ----------------------------------- 1 Unit

    PLC computer control ------------------------------ 1 Unit

    Output table ---------------------------------------- 1 Unit


    C). Working Flow


    Decoiler --- Feeding Guide --- Roll Forming --- Cut-to-length --- Run out table


    D). Applications


    Metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding


    E). Competitive Advantages


    1.Durable and widely used products

    2.Simple to operate when assemble

    3.Easy to handle the products

    4.Direct manufacturer, provide with high quality and best price.

    5.Provide sample in free.

    6.Products and design solution supplied fast and freely

    7.Best design oriented for your special requirements

    8.Lifelong technical support

    9.Professional team support


    F). More Reference Pictures



    ItemContact Methods
    Contact PersonLemon
    E-mail / Skypesales@wxtechwell.com
    Tel / Whatsapp+86-15861597732
    Reference video link

    https://youtu.be/hbmizYpbE2Q

    https://youtu.be/T5IKpomntU0
