Hot-dip Galvanizing Steel Cable Tray Roll Forming Machine for Making Cable Tray Sheet

A). Main Specifications

1. Material: Hot-dip Galvanizing steel strip
2. Material Thickness: 2.0mm,
3. Material Width: 400mm
4. Rolling Product Length: 0 limited, 0-any mm
5. Rolled Product Straightness Error: 1-1.5mm/1500mm
6. Rolling Product Angle Error: ≤±1.5/1000mm
7. Motors Explosion-proof Rating: ExdllCT4
8. Motor Protection: IP55
9. Total Installed Capacity Power: about 31.4 KW
10. Forming Station: 16 Steps
11. Speed of Line: 0-10m/min.
12. Weight of machine: about 11.5 Ton

B). Working Flow

Auoto Decoiler – Tranporting & 9 Rollers Leveling – Servo Feeding -- 100 Ton Punching machine --

Oriented – Transportation – 8 Holes Punching -- Main Forming -- Cutting -- Run out table

C). Applications

Cable tray, cable ladder, cable profile, tray profile

D). Competitive Advantages

High Quality

Reasonable Price

Good after Service

Factory Visit

1 Year Warranty

More Than 10 Years Experience

E). Reference Pictures
