    Hydraulic Cutting 13 - 22 Stations Tile Roll Forming Machine For Metal Roof Tile

    Ask Lasest Price
    Brand Name : TECHWELL
    Model Number : TW-GTM
    Certification : CE
    Price : Contact Us
    Payment Terms : 40% T/T in advance, 60% T/T before shipment
    Supply Ability : 20 sets
    Delivery Time : 55-65 working days
    • Product Details
    • Company Profile

    Hydraulic Cutting 13 - 22 Stations Tile Roll Forming Machine For Metal Roof Tile

    Forming Speed 0-15m/min Tile Roll Forming Machine For Metal Roof Tile With TW-GTM


    Main Specification


    MaterialThickness0.3-0.7mm
    Coil WidthCustomized, 1000mm or 1200mm or 1250mm
    Yield Strength250-300 Mpa
    MaterialPPGI,Color Steel,GI
    Decoiler/UncoilerUncoiler TypeManual or Hydraulic or Auto Type
    Coil WidthMax. 1250mm
    I.D508-610mm
    O.DMax. 1500mm
    Tile Roll Forming MachineForming Stations13-18 Stations ( Depend on Profiles )
    Roller material45# steel, surface coated with 0.05mm hard chrome
    Diameter of shaft76mm
    Shaft materialHigh grade 45# steel
    Drive typeChain transmission
    Forming speed0-15m/min
    Main power5.5KW

    • Hydraulic Station: Famous Chinese brand
    • Hydraulic Power: 5.5KW
    • Cutting type: Hydraulic cutting
    • Cutting Die Material: Cr12Mov steel, HRC58-62
    • CuttingTolerance: 10m+/-1.5mm
    • Encoder: OMRON Brand
    • PLC: PANASONIC Brand
    • Inverter: YASKAWA Brand
    • Touch screen: PANASONICE
    • Operation type:Touch screen & Button

    Components


    • Decoiler ---------------------------------------------- 1 Unit
    • Feeding guide -------------------------------------- 1 Unit
    • Main roll forming machine ------------------------ 1 Unit
    • Hydraulic pressing device -------------------------1 Unit
    • Hydraulic cutting device --------------------------- 1 Unit
    • Hydraulic Station ----------------------------------- 1 Unit
    • PLC computer control ------------------------------1 Unit
    • Output tables ---------------------------------------- 2 Units

    Work Flowing


    Decoiler --- Fedding Guide --- Film Covering --- Roll Forming --- Pressing --- Cut-to-length --- Run out table


    Application


    Glazed tile, Roof Tile, Metal roof tile; steel roof tile; color steel tile; color glazed tile; wave tile; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall claddin


    Advantages


    • High Quality
    • Reasonable Price
    • Good after Service
    • 1 Year Warranty
    • More Than 10 Years Experience

    Machine Pictures
