Material Thickness 0.3-0.7mm Roof Tile Making Machine With PLC Touch Screen Control

Main Specifications

Product Brand

• Electrical Control: PLC Frequency Control System with Touch Screen
• PLC: PANASONIC Brand
• Encoder: OMRON Brand
• Transducer: YASKAWA Brand

Main Parts

Decoiler --------------------------------------------- -1 Unit

Film covering device ------------------------------ 1 Unit

Feeding guide -------------------------------------- 1 Unit

Main roll forming machine ------------------------ 1 Unit

Hydraulic pressing device -------------------------1 Unit

Hydraulic cutting device --------------------------- 1 Unit

Hydraulic Station ----------------------------------- -1 Unit

PLC computer control ------------------------------ 1 Unit

Output table ---------------------------------------- --1 Unit

Working Flow

Decoiler ---> Fedding Guide ---> Roll Forming ---> Pressing ---> Cut-to-length ---> Run out table

Main Feature

• This Roof Tile Roll Forming Machine can rollform metal roof tiles. After roll formed by this tile roll forming machine, the surface of metal tile is very smooth and beautiful without any scratch on the surface of tile profile sheets.
• The Steel Roof Tile Roll Forming Machine is with fully automatic control system with PLC.
• Length, quantity of sheets is adjustable.
• Rollforming process: Decoiler, Rollforming, Pressing & Cut to length.
• Easy operation: Key in the length and quantity on the control panel.
• 1 Year warranty, lifelong time service.
• We also can do a custom roll forming machine, we can design machines according to your specifications and profile drawings, all our machines are customized.

Application

Glazed tile, Roof Tile, Metal roof tile; steel roof tile; color steel tile; color glazed tile; wave tile; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding

Advantages

• High Quality
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience
• Copra designing software
• 5-8 technicians every month specially do international installation and debugging

Tile Roll Forming Machine Pictures
