    U Profile Purlin Roll Forming Machine With Hydraulic Cutting Device Hydraulic Station

    Ask Lasest Price
    Brand Name : TECHWELL
    Model Number : TW-GTM
    Certification : CE
    Payment Terms : 40% T/T in advance, 60% T/T before shipment
    Supply Ability : 20 Sets
    Delivery Time : 55-65 working days
    Price : Contact Us
    • Product Details
    • Company Profile

    U Profile Purlin Roll Forming Machine With Hydraulic Cutting Device Hydraulic Station

    U Profile Purlin Roll Forming Machine With Hydraulic Cutting Device Hydraulic Station


    A). Main Components


    Decoiler ----------------------------------------------- 1 Unit

    Feeding & Leveling -------------------------------- 1 Unit

    Main roll forming machine ----------------------- 1 Unit

    Hydraulic cutting device --------------------------- 1 Unit

    Hydraulic Station ------------------------------------ 1 Unit

    PLC computer control ----------------------------- 1 Unit

    Output table ------------------------------------------ 1 Unit


    B). Working Flow


    Decoiler --- Fedding & Leveling --- Roll Forming --- Cut-to-length --- Run out table


    C). Main Specifications


    Material: HRC, CRC, GI

    Material thickness: 1.5-3.0mm

    Main power: 11KW

    Hydraulic power: 5.5KW

    Decoiler: Manual or hydraulic decoiler

    Weight capacity of decoiler: 5 Ton

    Axis diameter: 75mm

    Forming Station: 12 stations

    Principal axis material: 45# high grade steel, heated and quenched

    Roller material: GCr15 steel, quenched and heated process, HRC58-62

    Forming speed: 0-15m/min

    Drive: Chain transmission

    Electrical Control: PLC Frequency Control System with touch screen

    PLC: PANASONIC Brand

    Encoder: OMRON Brand

    Transducer: PANASONIC Brand


    D). Applications


    U purlin, U shaped purlin, U channel, U section, U profile, Ushape, Steel U purlin, U purlin steel structure


    E). Competitive Advantages


    High Quality

    Reasonable Price

    Good after Service

    1 Year Warranty

    More Than 10 Years Experience


    F). Machine Pictures
