Corrugated Profile Roof Roll Forming Machine For Making The Corrugated Sheets

Main Technical Specifications

1. Forming material type: PPGI, Color steel, GI
2. Forming material thickness: 0.3-0.8mm, yield strength: 250-350Mpa
3. Decoiler type: Manual or Hydraulic or Auto Type
4. I.D: 508-610mm
5. O.D: Max. 1500mm
6. Forming stations: about 16 Stations ( Depend on Profiles )
7. Roller material: 45# steel, surface coated with 0.05mm hard chrome
8. Diameter of shaft: 76mm
9. Shaft material: High grade 45# steel
10. Drive type: chain of transmission
11. Forming speed: 0-15m/min
12. Main power: 5.5KW
13. Cutting type: hydraulic cutting
14. Cutting die material: Cr12Mov steel, HRC58-62
15. Cutting power: 3.0KW
16. Cutting tolerance: 10m+/-1.5mm
17. Encoder: OMRON Brand
18. PLC: PANASONIC Brand

Working Flowing

Decoiler --- Fedding Guide --- Roll Forming --- Cut-to-length --- Run out table

Main Components

Competitive Advantages

• Copra designing software
• 5-8 technicians every month specially do international installation and debugging
• High Quality
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience

More Machine Pictures

Contacts of WUXI TECHWELL

Wuxi Techwell Machinery Co.,Ltd is a professional manufacturer specializing in the developing and exporting of cold roll forming machines and insulated sandwich panel machines and Slitting cutting machines.

Roll Forming Machines: Metal roof & wall panel roll forming machine, steel tile roll forming machine, dual level roll forming machine, C/Z/U/L shaped steel roll forming machine, drywall stud and track roll forming machine, steel floor deck roll forming machine, highway guardrail roll froming machinem downspout roll forming machine, rainwater gutter roll forming machine, portable downspout / gutter machines, door frame roll forming machine, roller shutter door roll forming machine, no-girder k span arched panel roll forming machine, slitting & cutting, roof curving machine, stacker machine and so on.

Insulated Sandwich Panel Machines: PU sandwich panel machine, rubber belt pu sandwich panel machine, continuous pu sandwich panel machine, EPS sandwich panel machine, rockwool sandwich panel machine, eps & rockwool sandwich panel machine, mineral wool sandwich panel machine and so on.

Wuxi Techwell engaged in the steel structure industry in many years and devoted to developing some steel structure machines with a professional technology and reasonable price, we supply the best machines for our new and old customers. In paticular, we are a leading exporter in the field of steel structure construction, and can provide professional service, high quality, through design and installation. Our goal is " Future by heartiness, faith leads to the world".

Warmly welcome to visit our factory and we are looking forward to cooperating with you for mutual benefits.
