Main Motor Power 7.5kw Roofing Sheet Making Machine / IBR Profile Roll Forming Machine

Main Specifications of IBR Sheet Making Machine

1. Model: Roofing Sheet Profile

2. Material: Color Steel, Iron, G.I Coils

3. Material thickness: 0.3-0.8mm

4. Material width: depend on customer’s requirement

5. Decoiler Type: manual or automatical type ( depend on customer’s requirement )

6. Weight Capacity Of Decoiler: 5 Ton

7. Main Motor Power: 7.5 Kw

8. Hydraulic Motor Power: 4.0 Kw

9. 14 Forming Station( depend on profile drawing )

10. Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.

11. Main Axis Material: High grade 45#, quenched and heat treatment.

12. Axis Diameter: ¢ 76mm

13. Working Speed: 0-15 m/min

14. Transporting Type: Chain Transmission

15. Type of Cutting: Hydraulic cutting

16. Material Of Cutting Blade: C r 12

17. Machine Frame stand: Welded structural steel

18. Electrical Control: PLC Frequency Control System with touch screen

Components of IBR Roofing Sheet

Reference Profile Drawing

Applications

IBR Roof Sheeting, IBR Sheeting, Chromadeck IBR Roofing, Trapezoidal roof panel, trapezoidal sheet,

trapezoidal roof metal, trapezoidal roofing, metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal

roofing sheet; steel roofing sheet

More Machine Pictures

Contact Details

Wuxi Techwell Machinery Co.,Ltd is a professional manufacturer specializing in the developing and exporting of cold roll forming machines and insulated sandwich panel machines and Slitting cutting machines.

Roll Forming Machines: Metal roof & wall panel roll forming machine, steel tile roll forming machine, dual level roll forming machine, C/Z/U/L shaped steel roll forming machine, drywall stud and track roll forming machine, steel floor deck roll forming machine, highway guardrail roll froming machinem downspout roll forming machine, rainwater gutter roll forming machine, portable downspout / gutter machines, door frame roll forming machine, roller shutter door roll forming machine, no-girder k span arched panel roll forming machine, slitting & cutting, roof curving machine, stacker machine and so on.

Insulated Sandwich Panel Machines: PU sandwich panel machine, rubber belt pu sandwich panel machine, continuous pu sandwich panel machine, EPS sandwich panel machine, rockwool sandwich panel machine, eps & rockwool sandwich panel machine, mineral wool sandwich panel machine and so on.

Wuxi Techwell engaged in the steel structure industry in many years and devoted to developing some steel structure machines with a professional technology and reasonable price, we supply the best machines for our new and old customers. In paticular, we are a leading exporter in the field of steel structure construction, and can provide professional service, high quality, through design and installation. Our goal is " Future by heartiness, faith leads to the world".

Warmly welcome to visit our factory and we are looking forward to cooperating with you for mutual benefits.
