    Gear Box Driving Type Purlin Roll Forming Machine For Making C / Z Channel With 1.5-3.0mm Thickness

    Ask Lasest Price
    Brand Name : TECHWELL
    Model Number : TW-C300
    Certification : CE, ISO
    Price : Contact Us
    Payment Terms : 40% T/T in advance, 60% T/T before shipment
    Supply Ability : 20 Sets
    Delivery Time : 55-65 Working Days
    • Product Details
    • Company Profile

    Gear Box Driving Type Purlin Roll Forming Machine For Making C / Z Channel With 1.5-3.0mm Thickness

    Gear Box Driving Type Purlin Roll Forming Machine For Making C / Z Channel With 1.5-3.0mm Thickness


    Technical Parameter


    NOItemParameterRemark
    1SuitableTypeGalvanized Coil
    WidthDepend on profile
    Thickness1.5-3.0mm
    Yield StrengthMax. 350Mpa
    2Forming Stationabout 18 StationsDepend on final design
    3Forming Speedabout 0-15m/min excluding punching, cutting time
    4Shaft Diameter80mm
    5Roller MaterialGCr15 SteelWith Hard Chrome
    6Drive TypeGear Box Drive
    7Punching ModelHydraullic Post Punching
    8Punching GroupsDepend on hole patterns
    9Cutting ModelHydraulic Cutting
    10Power SourceType380V/3PH/50HZOr Customized
    Main Power11 KW
    Hydraulic power7.5KW
    11PLC Control SystemPANASONICOperation; Screen + Button
    12Machine WeightAbout 10T

    Working Flowing Process


    Manual Decoiler --- Feeding Guide & Leveling Device --- Roll Forming --- Punchign & Cutting --- Run out table



    Main Components


    • Decoiler ----------------------------------------------------------------------- 1 Unit
    • Feeding & Leveling --------------------------------------------------------- 1 Unit
    • Main roll forming machine ------------------------------------------------- 1 Unit
    • Hydraulic punching device ------------------------------------------------ 1 Unit
    • Hydraulic cutting device --------------------------------------------------- 1 Unit
    • Hydraulic Station ------------------------------------------------------------ 1 Unit
    • PLC computer control ----------------------------------------------------- 1 Unit
    • Output table ------------------------------------------------------------------ 1 Unit

    Applications


    C purlin, c shaped purlin, c channel, lip channel, c section, c profile, c shape, steel c purlin, c purlin steel structure



    Reference Profile Drawing



    Competitive Advantaegs


    High Quality

    Reasonable Price

    Good after Service

    1 Year Warranty

    More Than 10 Years Experience

    Simple to operate when assemble

    Easy to handle the products

    Direct manufacturer, provide with high quality and best price.
