0.2 - 2.0 * 1300mm Simple Steel Coil Slitting Cutting Machine With 0 - 30m/min Speed

Main Specifications

1. Material specification:

• Material: Carbon steel, GI, Color steel – Q235-Q350
• Thickness: 0.2-2.0mm
• Width: 400-1300mm
• Inner diameter of coil: φ450—φ510
• Outer diameter of coil: φ1500mm. Max.
• Weight of coil: 5 Ton. Max.
• Diamter of slitting blades: φ120
• Material of slitting blades: 40Cr

2. Finished prodcuts data:

• Tolerance of width: ≤±0.02mm
• Max. strips to be slited: 10 pieces
• Min. width of the pieces: 50mm

Summary

• This line includes Uncoiler, Feeding Guide, Slitting Machine, Cantilevering Separating, Tension Control Board, Console and General electrical equipment.
• Electrical Source: 380V/50Hz/3Ph ( or depend on local requirement )²
• Speed of line: 0-30m/min.
• Main power: 30 KW
• Floor Area accupied by machine: 10m (L) x 3m ( Width )
• Production operation: 1 Skilled Worker, 1 common worker

Applications

Steel slitting cutting, metal slitting , metal sheet striping,

Our Advantage

• High Quality
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience

Working Video of Simple Slitting Machine
