17.7KW Electric Control K Span Arch Roof Roll Forming Machine For Large Span Roof
Main Specifications Of K Span Arch Roof Roll Forming Machine

• Thickness of sheet: 0.8-1.5mm
• Mounting dimension of K Span Arch Roof Roll Forming Machine: 8900mmx2250mmx2300mm
• Total weight: about 13 Ton
• Forming Station: 17 stations
• Control system: electric control
• Main motor power: 17.7KW
• Forming Power is 7.5KW
• Curving motor power: 4KW
• Electric cutting motor power: 4kw
• Conical Power is 2.2KW
• Material of rollers: 45# steel, quenched HRC58-62
• Material of shaft: 45# steel, adjusted
• Axis Diameter: 85mm
• Material of cutting blade: Cr12 steel
• Quenching hardness: HRC58-60

Working Flow

Decoiling—feeding—roll forming—-cut to length—product packing manual—arching—seaming

Main Components

K-Span Profile Drawings








Our Advantages

• High Quality
• Reliable
• Durable
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience

Machine Pictures
