Color Steel Hat Cap Roll Forming Machine For Making Metal Roof Ridge Tile

A). Main Specification of Roof Ridge Rolling Former

• Material thickness: 0.3-0.7mm
• Material width: depend on customer’s requirement
• Decoiler Type: manual or automatical type ( depend on customer’s requirement )
• Weight Capacity Of Decoiler: 5 Ton
• Main Motor Power: 5.5 Kw
• Hydraulic Motor Power: 7.5 Kw
• Forming Station: approx 15 ( depend on profile drawing )
• Axis Diameter: ¢ 75mm
• Working Speed: 0-15 m/min
• Transporting Type: Chain Transmission
• Heat Treatment of Cutting Blade: HRC 50-60
• Type of Cutting: Hydraulic cutting
• Electrical Control: PLC Frequency Control System with touch screen
• PLC: PANASONIC Brand
• Encoder: OMRON Brand
• Transducer: PANASONIC Brand
• Machine Weight: about 5 Ton

B). WorkinG Flow of Roof Ridge Rolling Former

Decoiler --- Fedding Guide --- Roll Forming --- Pressing --- Cut-to-length --- Run out table


C). Main Components of Roof Ridge Rolling Former

D). Reference Drawing of Roof Ridge Rolling Former

E). Application of Roof Ridge Rolling Former


Roof ridge cap, ridge cap, ridge tile; ridge valley; ridge flashing; valley flashing; top hat cap, top ridge cap.


F). Our Advantages of Roof Ridge Rolling Former

• Top Quality
• Free Custom- Made Design
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience

G). Reference Pictures of Roof Ridge Rolling Former
