    Metal Roof IBR Sheeting Roll Forming Machine For 0.3 - 0.8mm Material Thickness

    Ask Lasest Price
    Brand Name : TECHWELL
    Certification : CE
    Model Number : TW-RWM
    Price : Contact Us
    Delivery Time : 55-65 working days
    Payment Terms : 40% T/T in advance, 60% T/T before shipment
    Supply Ability : 20 sets
    • Product Details
    • Company Profile

    Metal Roof IBR Sheeting Roll Forming Machine For 0.3 - 0.8mm Material Thickness

    Metal Roof IBR Sheeting Roll Forming Machine For 0.3 - 0.8mm Material Thickness

    Main Specifications of IBR Sheeting Roll Forming Machine


    • Material thickness: 0.3-0.8mm
    • Material width: depend on customer’s requirement
    • Decoiler Type: manual or automatical type ( depend on customer’s requirement )
    • Weight Capacity Of Decoiler: 5 Ton
    • Main Motor Power: 5.5 Kw
    • Hydraulic Motor Power: 3 Kw
    • Forming Station: 13-20 ( depend on profile drawing )
    • Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
    • Main Axis Material: High grade 45#, quenched and heat treatment.
    • Axis Diameter: ¢ 76mm
    • Working Speed: 0-15 m/min
    • Transporting Type: Chain Transmission
    • Heat Treatment of Cutting Blade: HRC 50-60
    • Cutting Type of IBR Sheeting Roll Forming Machine: Hydraulic cutting
    • Material Of Cutting Blade: C r 12
    • Heat Treatment of Cutting Blade: HRC 50-60
    • Machine Frame stand: Welded structural steel
    • Thickmess of Fame Steel: 18mm
    • Electrical Control: PLC Frequency Control System with touch screen
    • PLC: PANASONIC Brand
    • Machine Weight: about 5 Ton

    Main Components


    Decoiler / Uncoiler1 Unit
    Feeding Guide1 Unit
    IBR Sheeting Roll Forming Machine1 Unit
    Hydraulic Cutting System1 Unit
    Hydraulic Station1 Unit
    PLC Computer Control Box1 Unit
    Support Tables2 Units

    Sample IBR Drawings


    Applications


    IBR Sheeting, IBR Sheets, Trapezoidal roof panel, trapezoidal sheet, trapezoidal roof metal, trapezoidal roofing, metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding
