    13 - 20 Forming Station Roof Wall Roll Forming Machine for Metal Roofing Sheet TW-RWM

    Ask Lasest Price
    Brand Name : TECHWELL
    Certification : CE
    Model Number : TW-RWM
    Price : Contact Us
    Delivery Time : 55-65 working days
    Payment Terms : 40% T/T in advance, 60% T/T before shipment
    Supply Ability : 20 sets
    • Product Details
    • Company Profile

    13 - 20 Forming Station Roof Wall Roll Forming Machine for Metal Roofing Sheet TW-RWM

    13 - 20 Forming Station Roof Wall Roll Forming Machine for Metal Roofing Sheet TW-RWM


    Characteristic of Roof Wall Sheet Roll Forming Machine


    1. This Roof Wall Sheet Roll Forming Machine can rollform metal roofing sheet. After roll formed by this roof roll forming machine, the surface of metal roofing is very smooth and beautiful without any scratch on the surface of roofing sheets.


    2. The Roof Wall Cladding Sheet Roll Forming Machine is with fully automatic control system with PLC.


    3. Length, quantity of sheets is adjustable.


    4. Rollforming process: Uncoiler, Rollforming, Cut to length.


    5. 1 Year warranty, lifelong time service.


    6. Easy operation: Key in the length and quantity on the control panel.


    7. We also can do a custom roll forming machine, we can design machines according to your specifications and profile drawings, all our machines are customized.

    Maintenance of Roof Wall Panel Roll Forming Machine


    Daily maintenance plays an very importance role in extending the operation time and of roof wall sheet roll forming machine and the good quality finished roof wall panel. The following points should be part of the machine's daily production and usage routine.

    • Regularly lubricated the outside parts of the roof wall roll forming machine, such as the driving chain...
    • Regularly brush the surface of roller, particularly when working outside. If you do not use the roof panel forming machine in a long time, you should apply luricating oil on the roller surface, make sure you clean it for next time running machine.
    • If the roof wall sheet roll forming machine is not operated in a long period, should cover it with plastic film, to avoid getting rain or dust on the machine, or avoid the machine becoming dampt, especially the PLC electric control board.
    • Make sure the cutting system is lubricated when necessary.
    • Check the Hydraulic station often and the oil quantity of the deceleration machines, add more oil if the oil level is low.
    • Check the electric appliances box and every leads conjuction circumstance of the roof wall roll forming machine.

    Specifications of Roof Wall Sheet Roll Forming Machine


    ItemRoof Wall Sheet Roll Forming Machine
    Coil MaterialThickness0.3-0.8mm
    Coil widthCustom-made, 1000mm or 1200mm or 1250mm
    Yield Strength250-350 Mpa
    MaterialPPGI, Color Steel, GI.
    Decoiler / UncoilerUncoiler TypeManual or Hydraulic or Auto Type
    Coil WidthMax. 1250mm
    I.D508-610mm
    O.DMax. 1500mm
    Roof Wall Roll Forming MachineForming Stations16-18 Stations ( Depend on Profiles )
    Roller material45# steel, surface coated with 0.05mm hard chrome
    Diameter of shaft76mm
    Shaft materialHigh grade 45# steel
    Drive typeChain transmission
    Forming speed0-15m/min
    Main power5.5KW
    Cutting DeviceCutting typeHydraulic cutting
    Cutting Die MaterialCr12Mov steel, HRC58-62
    Cutting power3KW
    CuttingTolerance10m+/-1.5mm
    EncoderOMRON Brand
    PLC Electrical Control SystemPLCPANASONIC Brand
    InverterYASKAWA Brand
    Touch screenPANASONICE
    Operation typeTouch screen & Button
    Hydraulic StationHydraulic stationFamous Chinese brand
    Runout TablesTable typeSimple nonpower type
    FunctionTo support the finished panels

    Composition of Roof Wall Roll Forming Machine


    Decoiler / Uncoiler1 Unit
    Feeding Guide1 Unit
    Roof Wall Sheet Roll Forming Machine1 Unit
    Hydraulic Cutting System1 Unit
    Hydraulic Station1 Unit
    PLC Computer Control Box1 Unit
    Support Tables2 Units

    Reference Sample Roof Wall Panel Drawings



    Roof Wall Panel Forming Machine Pictures
