    5.5 Kw Steel Metal Roof Roll Forming Machine With Manual, Automatical Decoiler

    Ask Lasest Price
    Brand Name : TECHWELL
    Certification : CE
    Model Number : TW-RWM
    Price : Contact Us
    Delivery Time : 55-65 working days
    Payment Terms : 40% T/T in advance, 60% T/T before shipment
    Supply Ability : 20 sets
    • Product Details
    • Company Profile

    5.5 Kw Steel Metal Roof Roll Forming Machine With Manual, Automatical Decoiler


    5.5 Kw Steel Metal Roof Roll Forming Machine With Manual, Automatical Decoiler

    A). Specifications of Metal Roof Roll Forming Machine


    • Material thickness: 0.3-0.8mm
    • Material width: depend on customer’s requirement
    • Decoiler Type: manual or automatical type ( depend on customer’s requirement )
    • Weight Capacity Of Decoiler: 5 Ton
    • Main Motor Power: 5.5 Kw
    • Hydraulic Motor Power: 3 Kw
    • Electrical Control: PLC Frequency Control System with touch screen
    • PLC: PANASONIC Brand
    • Encoder: OMRON Brand
    • Transducer: PANASONIC Brand
    • Machine Weight: about 5 Ton
    • Forming Station: 13-20 ( depend on profile drawing )
    • Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
    • Main Axis Material: High grade 45#, quenched and heat treatment.
    • Axis Diameter: ¢ 76mm
    • Working Speed: 0-15 m/min
    • Transporting Type: Chain Transmission
    • Heat Treatment of Cutting Blade: HRC 50-60
    • Type of Cutting: Hydraulic cutting
    • Material Of Cutting Blade: C r 12
    • Heat Treatment of Cutting Blade: HRC 50-60
    • Machine Frame stand: Welded structural steel
    • Thickmess of Fame Steel: 18mm

    B). Compositions of Metal Roof Roll Forming Machine


    Decoiler / Uncoiler1 Unit
    Feeding Guide1 Unit
    Metal Roof Sheet Roll Forming Machine1 Unit
    Hydraulic Cutting System1 Unit
    Hydraulic Station1 Unit
    PLC Computer Control Box1 Unit
    Support Tables2 Units

    C). Maintenance of Metal Roof Roll Forming Machine


    Daily maintenance plays an very importance role in extending the operation time and of Metal roof sheet roll forming machine and the good quality finished metal roofing. The following points should be part of the machine's daily production and usage routine.


    1. Regularly lubricated the outside parts of the trapezoidal roofing sheet roll forming machine, such as the driving chain...
    2. Regularly brush the surface of roller, particularly when working outside. If you do not use the trapezoidal roof panel forming machine in a long time, you should apply luricating oil on the roller surface, make sure you clean it for next time running machine.
    3. If the Trapezoidal sheet roll forming machine is not operated in a long period, should cover it with plastic film, to avoid getting rain or dust on the machine, or avoid the machine becoming dampt, especially the PLC electric control board.
    4. Make sure the cutting system is lubricated when necessary.
    5. Check the Hydraulic station often and the oil quantity of the deceleration machines, add more oil if the oil level is low.
    6. Check the electric appliances box and every leads conjuction circumstance of the trapezoidal roof sheet roll forming machine.

    D). Reference Roof Profile Drawings



    E). Our Advantages


    • After-sales service
    • High Quality
    • Technical Support

    Fully providing technology supports both within and after the warranty period. Feed back to our customers at the first time.

    • Spare Parts

    Promptly providing spare parts and wearing parts.

    • Upgrade

    Improve technology and upgrade of equipments.

    • 1 Year Warranty
    • More Than 10 Years Experience

    F). Reference Machine Pictures of Roof Forming Machine




    G). Contact Us Freely


    CompanyWuxi Techwell Machinery Co.,LTD
    Websitewww.cold-rollformingmachine.com
    www.roofrollformingmachine.com
    www.wxtechwell.com
    Videowww.youtube.com/wxtechwell
    Tel / Fax0086-510-83133431
    Mobile0086-18018304331 ( Miss Lee )
    E-Mailmonica@wxtechwell.com
    Skypemonica198614
    MSNlixiaohua_monica@hotmail.com

    H). FAQ


    1. How to get a accurate quotation from us?
    a. Material width and thickness. b. drawing of profile.
    As for the drawing, you can provide by yourself, or choose from our standard profiles.

    2. How to repair & maintain our Roll Forming Machine?

    a. Normally, the machine can work without problem for at least 5 years.
    b. If you have problem, do not change the machine by yourself. Tell us the problem, and we help you to solve it step by step.

    3. What policy for broken parts?
    Within the ONE-YEAR period, we could supply you the replacement parts free of charge for any damaged parts caused by quality problems. After one year, you need to buy by factory cost.
