    0.3 - 0.8mm Material Thickness Color Steel Roof Roll Forming Machine TW-RWM

    Ask Lasest Price
    Brand Name : TECHWELL
    Certification : CE
    Model Number : TW-RWM
    Price : Contact Us
    Delivery Time : 55-65 working days
    Payment Terms : 40% T/T in advance, 60% T/T before shipment
    Supply Ability : 20 sets
    • Product Details
    • Company Profile

    0.3 - 0.8mm Material Thickness Color Steel Roof Roll Forming Machine TW-RWM

    0.3 - 0.8mm Material Thickness Color Steel Roof Roll Forming Machine TW-RWM


    A). Compositions of Roof Panel Roll Forming Machine


    Decoiler / Uncoiler1 Unit
    Feeding Guide1 Unit
    Steel Roof Roll Forming Machine1 Unit
    Hydraulic Cutting System1 Unit
    Hydraulic Station1 Unit
    PLC Computer Control Box1 Unit
    Support Tables2 Units

    B). Reference Specifications of Roof Panel Roll Forming Machine


    • Electrical Control: PLC Frequency Control System with touch screen
    • PLC: PANASONIC Brand
    • Encoder: OMRON Brand
    • Inverter: YASKAWA Brand
    • Touch Screen: MCGS Brand
    • Machine Weight: about 5 Ton
    • Material thickness: 0.3-0.8mm
    • Material width: depend on customer’s requirement
    • Main Motor Power: 5.5 Kw
    • Hydraulic Motor Power: 3 Kw
    • Forming Station: 13-20 ( depend on profile drawing )
    • Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
    • Main Axis Material: High grade 45#, quenched and heat treatment.
    • Axis Diameter: ¢ 76mm
    • Working Speed: 0-15 m/min
    • Transporting Type: Chain Drive
    • Type of Cutting: Hydraulic cutting
    • Material Of Cutting Blade: C r 12

    C). Characteristic of Roof Panel Roll Forming Machine


    • This Steel Roof Profile Roll Forming Machine can rollform metal roofing panel sheet. After roll formed by this roof sheet roll forming machine, the surface of iron roof wall panel is very smooth and beautiful without any scratch on the surface of profile sheets.
    • The Metal Roof Sheet Roll Forming Machine is with fully automatic control system with PLC.
    • Length, quantity of sheets is adjustable.
    • Rollforming process: Decoiler, Rollforming, Cut to length.
    • Easy operation: Key in the length and quantity on the control panel.
    • 1 Year warranty, lifelong time service.
    • We also can do a custom roll forming machine, we can design machines according to your specifications and profile drawings, all our machines are customized.

    D). Reference Roof Drawings of Roof Panel Roll Forming Machine



    E). Pictures of Roof Panel Roll Forming Machine



    F). Customer Visiting



    G). Contact us freely
