    Metal Automatical Roof Panel Cold Roll Forming Machine with 0 - 15 m/min Speed

    Ask Lasest Price
    Brand Name : TECHWELL
    Certification : CE, BV
    Model Number : TW-18-228.5-914
    Price : Contact Us
    Delivery Time : 55-65 working days
    Payment Terms : 40% T/T in advance, 60% T/T before shipment
    Supply Ability : 20 sets
    • Product Details
    • Company Profile

    Metal Automatical Roof Panel Cold Roll Forming Machine with 0 - 15 m/min Speed


    Metal Automatical Roof Panel Cold Roll Forming Machine with 0 - 15 m/min Speed


    Main Specifications of Roof Panel Roll Forming Machine


    Coil Material

    Thickness0.3-0.8mm
    Coil width1000mm or custom-made
    Yield Strength250-350Mpa
    MaterialPPGI, Color Steel,
    Decoiler / UncoilerCoil Width1250mm
    I.D508-610mm
    O.DMax. 1500mm
    Roll Forming MachineForming Stations16 Stations ( Depend on Profiles )
    Roller material45# steel, surface coated with 0.05mm hard chrome
    Diameter of shaft76mm
    Shaft materialHigh grade 45# steel
    Drive typeChain transmission
    Forming speed0-15m/min
    Main power5.5KW
    CuttingCutting typeHydraulic cutting
    Cutting power3KW
    Cutting Tolerance10m+/-1.5mm
    EncoderOMRON Brand
    Electrical controlPLCPANASONIC Brand or Custom-made
    InverterYASKAWA Brand or Custom-made
    Touch screenMCGS Brand or Custom-made
    Operation typeTouch screen & Button
    Hydraulic StationHydraulic stationFamous Chinese brand
    Runout TableTable typeSimple nonpower type
    FunctionTo support the finished panels

    Main Components of Roof Panel Roll Forming Machine


    Decoiler / Uncoiler1 Unit
    Feeding Guide1 Unit
    Main Roll Forming Machine1 Unit
    Hydraulic Cutting Device1 Unit
    Hydraulic Station1 Unit
    PLC Computer Control Board1 Unit
    Runout Table2 Units

    Roof Panel Profile Drawing


    Applications



    Metal roof panel, Metal Roof sheet, trapezoidal roof metal, trapezoidal roofing, metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding


    TECHWELL Advantage


    • High Quality
    • Reasonable Price
    • Good after Service
    • 1 Year Warranty
    • More Than 10 Years Experience

    Photos of Roof Panel Roll Forming Machine
